Paver Grate

Discreet Drainage CHANNEL For Architectural Pavers

PolyDrain PaverGrate® is a discrete slot drain system designed to provide a nearly invisible surface drain option when used in conjunction with brick or stone pavers.

With a 5/16″ (7.9mm) opening, PaverGrate® is both ADA and Heel Proof.

Paver Grate
Longitudinal Anchor Joint Polylock Inserts PolyLock Retention ADA Compliant and Heel-Safe Numeric Labeling Directional Arrow Interlocking Joints Polymer Concrete Sloping Radius Bottom

Longitudinal Anchor Joint

The full-length keyway joint mechanically anchors the channel to the surrounding concrete encasement.

Polylock Inserts

Vibration dampening inserts help keep grates secure under load conditions.  PolyDrain channels feature RedDot polyethylene or GreenDot polypropylene inserts.

PolyLock Retention

Locking devices are recommended for all applications with loading requirements greater than residential and pedestrian traffic or where vandalism may be an issue.

ADA Compliant and Heel-Safe

Paver Grate

Available with a 5/16″ or 1/4" slot, PaverGrate is both ADA and Heel-Safe.

Numeric Labeling

PolyDrain channels feature cast numeric labels to make installation easy and simple.

Directional Arrow

PolyDrain channels feature cast directional arrows to indicate the direction of water flow and ensure proper layout and installation.

Interlocking Joints

Interlocking tongue and groove joints aid positive alignment and provide a tighter joint.

Polymer Concrete

All PolyDrain channels are available in two polymer concrete formulations. Both offer superior strength and durability over alternative materials. All PolyDrain Polyester channels are UL classified.

Sloping Radius Bottom

PolyDrain channels have a built-in 0.6% slope and smooth radius bottom.

Paver Channel Drainage

Our Paver Grate discrete slot drain systems provide discrete functionality for all your commercial applications. Our pedestrian-friendly discrete slot drain grates feature one of the narrowest openings in the industry, making them completely ADA-compliant and heel-proof. We secure each Paver Grate to an accompanying polymer channel with galvanized or stainless steel PolyLock bolts—this step ensures your grates stand up to high-volume load requirements. Our pre-cast concrete trench drain features a built-in slope with seamless interlocking joints to make the installation process a breeze. For patios, sidewalks, and other brick or stone construction jobs, the PolyDrain PaverGrate® is the perfect paver grate and channel drainage system

Selecting a fire-resistant trench drain system should be common practice for any interior application.  Trench Drains are often the collection points for flammable fluids and heavier-than-air vapors.  As a result, even when empty, trenches can act as a pathway for flame spread. For more info, see our Flame and Smoke page.
